AF-1000 PEEK POM Solid Board Plate Sheet Extrusion Machine

AF-1000 PEEK POM Solid Board Plate Sheet Extrusion Machine

1. Brand & Manufacturing Strength

YAOAN is a leading professional manufacturer deeply specialized in the R&D and production of high-performance engineering plastic extrusion equipment, with40 years of mature experience in rod and plate extrusion technology. Owning an independent R&D team and a large-scale factory covering 80,000 square meters, we master core autonomous technology and continuous technological iteration capabilities. Our equipment features advanced design, superior stability and leading performance in the domestic industry, holding a top-tier position in the field of super engineering plastic extrusion.

With reliable quality and excellent technical strength, our extrusion lines have been successfully exported to Germany, the United States, Japan, Singapore, Russia, Israel, Italy, Turkey, Romania and many other countries and regions, gaining wide recognition and long-term trust from global customers.

2. Product Overview

YAOAN dual-purpose PEEK rod & thick plate extrusion line is a newly upgraded multi-functional extrusion equipment independently developed for high-performance super engineering plastics. Breaking the limitation of single production function of traditional extrusion machines, this equipment supports switchable production of both PEEK/POM solid rods and thick plates with one single line, realizing dual-purpose production and maximizing customer production benefits.

Aiming at the characteristics of high melting point, high viscosity and easy residual carbon of PEEK and POM materials, the line adopts advanced high-temperature plasticization technology, precise gradient cooling system and special quick-cleaning screw design. It effectively solves industry pain points such as difficult screw cleaning, troublesome material switching, plate/rod warping, uneven thickness and internal stress defects. With advanced overall design and first-class comprehensive performance, it is a highly cost-effective and multi-functional core equipment for high-end engineering plastic profile production.

3. Core Technical Parameters

• Applicable Raw Materials: High-purity PEEK resins, POM resins (100% virgin material)

• Production Specification Range: 8mm ~ 100mm, supporting both thick plate and solid rod production

• Equipment Center Height: 1100±50mm, enhanced structural stability for heavy and thick profile molding

• Core Feature: Dual-purpose for plate & rod production, fast screw disassembly and easy cleaning

4. Complete Equipment Configuration List

The full set of dual-purpose extrusion line consists of 7 core units with scientific and reasonable process layout. All units operate coordinately to realize fully automated, continuous and stable production of PEEK/POM plates and rods, with high molding accuracy and excellent finished product consistency:

5. Equipment Core Advantages

5.1 Dual-Purpose Design for Plate & Rod, Wide Application

Different from single-function traditional extrusion equipment, this innovative dual-purpose line can freely switch between PEEK/POM thick plate and solid rod production, covering the full specification range of 8mm–100mm. The 1100±50mm high center height reinforced structure perfectly adapts to the molding of super-thick, heavy and large-size profiles, solving the problems of sagging, uneven thickness and poor straightness of thick profiles, greatly enriching product categories and lowering customer equipment investment costs.

5.2 Unique Quick-Cleaning Screw Structure, Low Maintenance Cost

Aiming at the problem of difficult cleaning and easy carbon deposition of high-viscosity PEEK/POM materials, the equipment adopts a specially optimized detachable screw structure. It supports fast disassembly and assembly of the screw and barrel without complicated procedures, enabling thorough cleaning of residual materials and carbon deposits in a short time. It greatly shortens production switching downtime, improves production flexibility, and solves the long-standing industry pain point of difficult maintenance of high-temperature engineering plastic extrusion equipment.

5.3 Low Internal Stress & High Dimensional Stability

Equipped with professional quenching rapid shaping and dual-stage gradient cooling system, the equipment precisely controls the internal and external cooling speed of plates and rods, effectively eliminates internal stress, and ensures no warping, no deformation and no cracking of finished products. The extruded profiles feature uniform density, no bubbles, no impurities and stable physical and chemical properties, meeting the strict production standards of high-end industrial precision parts.

5.4 Advanced Design & Leading Domestic Technology

Benefiting from 40 years of accumulated extrusion technology and independent R&D capabilities, the equipment adopts industry-leading structural design and parameter configuration. Compared with ordinary extrusion lines, it has higher plasticization efficiency, more stable operation, lower failure rate and better finished product consistency. Its overall technical level ranks first-class in China, capable of competing with international advanced equipment.

5.5 Mature Export Experience & Reliable Strength Guarantee

With 80,000㎡ standardized production base and independent core technology, YAOAN has long-term mature export experience. Our equipment has been stably operated and recognized in many developed countries and regions worldwide. We provide one-stop services including customized equipment solutions, factory installation & commissioning, technical training and perfect after-sales support, delivering high-quality and high-reliability extrusion equipment for global customers.

6. Application Fields

This dual-purpose extrusion line is dedicated to producing high-performance PEEK and POM thick plates & solid rods, widely applicable in aerospace, medical equipment, semiconductor electronics, precision machinery, chemical corrosion resistance, new energy, automotive manufacturing and other high-end fields. The finished profiles can be directly used for precision processing of high-temperature resistant, wear-resistant, insulating and corrosion-resistant parts, helping customers expand product lines and occupy the high-end engineering plastic material market.
