PP meltblown Nonwoven Fabric Slitting Machine

PP meltblown Nonwoven Fabric Slitting Machine

PP meltblown Nonwoven Fabric Slitting Machine

Product Details:

Place of Origin: CHINA
Brand Name: YAOAN
Certification: CE
Model Number: AF-1600,2400,3200

Payment & Shipping Terms:

Delivery Time: 30 DAYS
Payment Terms: L/C, T/T, Western Union
Contact Now
Detailed Product Description

This kind slitting machine is suitable for slitting various plastic film, glassine, nonwoven fabric, aluminum foil, paper, photo-sensitive material etc. Microcomputer control, adopts machinery-electronics integration controller, automatic rectifying deviation, automatic counting, auto-stop when reach to preset meter, constant tension controller and step less speed regulator, high speed, slitting materials neatly and so on.

Parameter:

Unwinding length: 1600mm
Max.diameter of unwinding: 800mm
Max.diameter of rewinding: 600mm
Slitting size: minimum 30,38,40mm
Speed: 20—80m/minute

Total power: 2.2kw
Weight: 1000kg

Overall dimension (l*w*h):2500mm*1800*1200mm



Configuration:

Slitting machine (slitter one big roll into small roll)

Unwinding materials: unwinding material fixed by air cylinder

Unwinding material: left and right could be adjusted.

Rewinding tension adopt 5kg magnetic powder brake, rewinding up and down

Cutter: 30 pieces
Edge correction motor: meifeng
Converter motor: kewo

Electrical: chint
Pneumatic: SNS

Magnetic powder: shengda

Spare parts:
socket wrench
monkey wrench
screwdriver
oil gun
panel switch
knife: 30
