PPR Pipe Extrusion Machine

PPR Pipe Extrusion Machine

PPR Pipe Extrusion Machine

Product Details:

Place of Origin: CHINA
Brand Name: YAOAN
Certification: CE
Model Number: 65

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: WOODEN BOX
Delivery Time: 30-90 DAYS
Payment Terms: TT,LC
Supply Ability: 100 SETS PER MONTH
Contact Now
Detailed Product Description

● PPR extruder machine: special for manufacturing of PP-R cold & hot water pipe according to the standard of ISO/ DIS 15874.2-1999.
● Extruder: single screw extruder adopts latest groove barrel, LTM high efficiency screw which provides high rotation speed, output and plasticization capability.
● Extrusion mould: adopts latest spiral die head, which features even extruding, easy operation and adjustment.
● Vacuum calibration device: vacuum spraying water chamber, spraying cooling tank or high efficiency water tank, tank body is made of stainless steel.
● Haul off unit: double-belt or two-bedrail haul off unit to satisfy the different requirement of production.
● Cutting unit: chipless rotary saw cutting.
● Stacking unit: automatic overturning or roller stacking unit, can design dual-shaft winding unit for small pipe.
● Electric control system: many types of control system are available for selection (such as PLC automatic control system) high production speed, stable running and easy operation.

PPR Pipe Extrusion Machine
